Product Information

CTCP Plate is able to meet various requirements of high grade commercial and newspaper printing. It has the advantages of fast plate making speed, high tolerance level, precise half-tone dot reproduction, good ink balance and high press run length.

2.Characteristic
1) High quality aluminum, composite grain and high press runs.
2) Capable of bright room operation.
3) High resolution and precise half tone dot reproduction.
4)High development tolerance level and convenient operation.

3.Specification

Model: ECOO-ED

No preheat, positive-working, thermal digital plate with excellent chemical and press durability;

Exposure energy required: 110-120 mj/ cm2 (depend on imager type, configuration and resolution)

Resolution: 1-99% @400lpi or 10μ FM stochastic (depend on capability of imaging device)

Spectral sensitivity: 780-850 nm

Run-length: 100,000 impressions unbaked; 50,000 impressions for UV ink applications,300,000 plus impressions baked(dependent upon image resolution, press, press chemical, ink and paper conditions).

Gauges: 0.15mm, 0.30mm and 0.40mm standard, with 0.20mm and 0.24mm availability in selected regions.

Coating color: Blue

Safelight: Daylight handling

Shelf life: 12 months, under recommended storage conditions.

Model	ECOO-ED
Plate Type	Positive Thermal CTP Plate Double Layer
Application	High grade commercial and newspaper printing
Substrate	Electro chemically Grained and Anodized lithographic Aluminum
Aluminum alloy	Standard 1050 Alloy
Coating	Single-layer coating, IR sensitive
Gauge	0.15,0.20, 0.25,0.30, 0.40 (mm)
Maximum short grain width	Maximum width 1280 mm
Plate intermix	Kodak Electra Excel HRL/HRO Thermal Plates, Kodak Sword Ultra Thermal Plates, Kodak Capricorn Excel Positive Plates, Kodak PP3 positive plates, Agfa Energy Elite, etc.
Length of Run	Unbaked: 100000 or more
	Baked: Over 100000 impressions

Exposing
Plate setters	Kodak Trendsetter/Lotem/Magnus; Fuji Javelin T9000HS; Heidelberg Topsetter/Suprasetter; Screen PT-R; Creo Scitex , or EcooGraphix thermal CTP T series
Exposure energy	90 - 110 mj /cm²
Spectral Sensitivity	800-850 nm - Peaks 830nm
Resolution	1-99% at 300 LPI
FM capability	20 micron stochastic
Image color	Blue
Developing
Processor	All Brands.
Developer	Kodak Gold Star or our own developer
Processing temperature	23°C +/- 2°C
Developing time	25 - 30 sec
Processing Speed	0.80 - 1.20 m/min
Storage and handling	Daylight handling
Safe Light
Shelf Life	12 months under recommended storage conditions
Packaging	Available in all standard formats, including bulk packaging options such as APL packaging
Storage and handling	stored in a cool and dry environment, away from excessive cold, heat and humidity.

4.Recommended Image Data

CTP model Data	Kodak trendsetters	LOTTEM 400(TH1.7)	MAGNUS 400	Screen 8600S
Laser power	13-15W	270-280mw	17-19W	70-80 %
Drum speed	250-300rpm	850-900rpm	400-450rpm	800-900rpm
Resolution	Customized	Customized	Customized	Customized
Parameter that need set up	Focus/ Zoom	Focus/ Zoom	Focus/ Zoom	Focus/ Zoom

*Note: Higher exposure energy will make the image contrast more clear, and benefit to the plate run length; while over high/low exposure energy will affect the image quality negatively.
